SPECIFICATION
| Standard(s) | BS EN60669-2-1 |
| Rating | 32Amp , 220-240V~ |
| Suitable Card | 54mm Width ,0.6mm-1mm Thickness |
| Switch Type | N/A |
| Contact Gap | Micro Gap |
| Terminal Capacity | 3x 2.5mm² ,2x 4.0mm²，1x 6.0mm² |
| Mounting Box Depth(Min) | 47mm |
| Fixing Centres | 60.3mm |
| Size | 86mmx86mmx4.5mm（Plate thickness） |
| Product Class 1 | Face plate must be earthed |
| Ambient Operating Temperature | -5° to +40°C |
| Recommended Location | Internal Use Only |
| Maximum Installation Altitude | 2000m |
| IP Rating | IP2XD |
LINE DIAGRAM
